Siemens CU240S DP-F Parameter Manual

Technology Functions
Function diagrams
2-349
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Fig. 2-27 4600 – Vdc Control (max, min)
CO/BO:Stat MotCtrl
r0056 r0056
r1246 [3]
KIB ON level [V]
- 4600 -
Function diagram
87654321
4600.vsd
Technology Functions
SINAMICS G120
02.04.2007 V3.0
Vdc Control (max, min)
1,3
0,2
0
– –
2,3
0,1
0
<20
20
1
f(V
DC
)
FP 6100
.14
isq(V
DC
)
FP 7900
r0056.15
100
2
r0070
Act. Vdc [V]
r0070
Act. Vdc [V]
r1242
Vdc-max ON lev [V]
Vdc controller
0 ... 3
P1240.DDS (0)
Vdc controller
0 ... 3
P1240.DDS (0)
Supply voltage
0 ... 1000 [V]
P0210 (400)
KIB ON level
65 ... 115 [%]
P1245.DDS (76)
Vdc-max dyn. fact.
10 ... 200 [%]
P1243.DDS (100)
Dyn. factor of KIB
10 ... 200 [%]
P1247.DDS (100)
Gain of Vdc ctrl.
0.00 ... 10.00
P1250.DDS (1.00)
Diff.time Vdc ctrl
0.0 ... 1000.0 [ms]
P1252.DDS (1.0)
Int. time Vdc ctrl
0.1 ... 1000.0 [ms]
P1251.DDS (40.0)
Control mode
0 ... 23
P1300.DDS (0)
Vdc ctrl outp. lim
0.00 ... 600.00 [Hz]
P1253.DDS ( 10.00)
