List of Parameters
Parameters
1-235
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Lower limit threshold value 3 for comparing actual torque.
Note: See P2182 (belt threshold frequency 1).
Description: P2192 defines a delay before warning/trip becomes active.
It is used to eliminate events caused by transient conditions.
It is used for both methods of fault detection.
Description: Monitoring word 1 which indicates the state of monitor functions.
Each bit represents one monitor function.
p2190[0...2] Lower torque threshold 3 / Lower trq. thresh3
Access level: 2 P-Group: Messages Data type: Floating Point
Quick comm. NO Active: YES Data set: DDS
Can be changed: U, T
Min Max Factory setting
0.0 [Nm] 99999.0 [Nm] 0.0 [Nm]
p2192[0...2] Time delay for belt failure / Belt fail delay_T
Access level: 2 P-Group: Messages Data type: Unsigned16
Quick comm. NO Active: YES Data set: DDS
Can be changed: U, T
Min Max Factory setting
0 [s] 65 [s] 10 [s]
r2197.0...12 CO/BO: Monitoring word 1 / Monitor Wd1
PM240 Access level: 2 P-Group: Messages Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 f_act <= P1080 (f_min) Yes No -
01 f_act <= P2155 (f_1) Yes No -
02 f_act > P2155 (f_1) Yes No -
03 f_act > zero Yes No -
04 f_act >= setp. (f_set) Yes No -
05 f_act <= P2167 (f_off) Yes No -
06 f_act >= P1082 (f_max) Yes No -
07 f_act == setp. (f_set) Yes No -
08 Act. current r0068 <= P2170 Yes No -
09 Act. unfilt. Vdc < P2172 Yes No -
10 Act. unfilt. Vdc > P2172 Yes No -
11 Load missing Yes No -
12 f_act > P1082 with delay Yes No -
