Parameters
List of Parameters
1-258
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Output of AND 1 element.
Displays and logic of bits defined in P2810[0], P2810[1].
Dependency: P2801[0] is active level for the AND element.
Description: P2812[0], 2812[1] define inputs of AND 2 element, output is P2813.
Index: [0] = Binector input 0 (BI 0)
[1] = Binector input 1 (BI 1)
Dependency: P2801[1] is active level for the AND element.
Description: Output of AND 2 element.
Displays and logic of bits defined in P2812[0], P2812[1].
Dependency: P2801[1] is active level for the AND element.
Description: P2814[0], P2814[1] define inputs of AND 3 element, output is P2815.
Index: [0] = Binector input 0 (BI 0)
[1] = Binector input 1 (BI 1)
Dependency: P2801[2] is active level for the AND element.
Description: Output of AND 3 element.
Displays and logic of bits defined in P2814[0], P2814[1].
Dependency: P2801[2] is active level for the AND element.
r2811.0 BO: AND 1 / AND 1
Access level: 3 P-Group: Technology Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Output of BO Yes No -
p2812[0...1] BI: AND 2 / AND 2
Access level: 3 P-Group: Technology Data type: Unsigned32
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
- - 0
r2813.0 BO: AND 2 / AND 2
Access level: 3 P-Group: Technology Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Output of BO Yes No -
p2814[0...1] BI: AND 3 / AND 3
Access level: 3 P-Group: Technology Data type: Unsigned32
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
- - 0
r2815.0 BO: AND 3 / AND 3
Access level: 3 P-Group: Technology Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Output of BO Yes No -
