Siemens CU240S DP-F Parameter Manual

List of Parameters
Parameters
1-241
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Defines command source of fixed PID setpoint selection Bit 1.
Description: Defines command source of fixed PID setpoint selection Bit 2.
Description: Defines command source of fixed PID setpoint selection Bit 3.
Description: Defines command source of fixed PID setpoint selection Bit 3.
Description: Displays total output of PID fixed setpoint selection.
Note: R2224 = 100 % corresponds to 4000 hex.
Description: Displays the status of PID fixed frequencies.
p2221[0...2] BI: Fixed PID setp. select Bit 1 / BI:PID setp->Bit 1
Access level: 3 P-Group: Commands Data type: Unsigned32
Quick comm. NO Active: NO Data set: CDS
Can be changed: T
Min Max Factory setting
- - 722.4
p2222[0...2] BI: Fixed PID setp. select Bit 2 / BI:PID setp->Bit 2
Access level: 3 P-Group: Commands Data type: Unsigned32
Quick comm. NO Active: NO Data set: CDS
Can be changed: T
Min Max Factory setting
- - 722.5
p2223[0...2] BI: Fixed PID setp. select Bit 3 / BI:PID setp->Bit 3
CU240E
CU240S DP-F
Access level: 3 P-Group: Commands Data type: Unsigned32
Quick comm. NO Active: NO Data set: CDS
Can be changed: T
Min Max Factory setting
- - 0
p2223[0...2] BI: Fixed PID setp. select Bit 3 / BI:PID setp->Bit 3
CU240S
CU240S DP
CU240S PN
Access level: 3 P-Group: Commands Data type: Unsigned32
Quick comm. NO Active: NO Data set: CDS
Can be changed: T
Min Max Factory setting
- - 722.6
r2224 CO: Act. fixed PID setpoint / Fixed.PID setp
Access level: 2 P-Group: Technology Data type: Floating Point
Unit: [%] Data set: -
r2225.0 BO: PID Fixed frequency status / PID FF Status
Access level: 3 P-Group: Commands Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Status of FF Yes No -
