List of Parameters
Parameters
1-189
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Control word of motor data identification.
Description: Performs a motor data identification with extended figures.
Values: 0: Disabled
1: Identification of all parameters with parameter change
2: Identification of all parameters without parameter change
3: Identification of saturation curve with parameter change
4: Identification of saturation curve without parameter change
5: Identification of XsigDyn (r1920) without parameter change
6: Identification of Tdead (r1926) without parameter change
7: Identification of Rs (r1912 ) without parameter change
8: Identification of Xs (r1915) without parameter change
9: Identification of Tr (r1913) without parameter change
10: Identification of Xsigma (r1914) without parameter change
20: Set voltage vector
21: Set voltage vector without filtering in P69
22: Set voltage vector rectangle signal
23: Set voltage vector triangle signal
Caution: Motor identification should be performed on a cold motor.
However, the identification of the motor data should only be performed if the motor temperature is within 5°C of the
measured ambient temperature stored in P0625.
If the motor identification is not within the 5°C limit then the correct functioning of Vector Control (SLVC) cannot be
guaranteed.
The motor rating plate information with respect to the connection of the motor windings (Star or delta connection)
must be correct in order to establish the correct equivalent circuit data.
The motor identification calculates this data based on a Phase of a Star equivalent circuit P0350 - P0360, irrespec-
tive of whether the motor is connected star or delta.
This must be considered when the motor data is inputed directly.
p1909[0...2] Ctrl. word of motor data ident. / Ctrl.mot.data id.
Access level: 4 P-Group: Motor identification Data type: Unsigned16
Quick comm. NO Active: NO Data set: DDS
Can be changed: U, T
Min Max Factory setting
- - 0101 1100 0000 0000 bin
Bit field: Bit Signal name 1 signal 0 signal FP
00 Estimation of Xs Yes No -
02 Estimation of Tr Yes No -
03 Estimation of Lsigma Yes No -
05 Det. Tr meas. with 2 freq. Yes No -
06 Measurement of on voltage Yes No -
07 Deadtime detection from Rs measurement Yes No -
08 MotID with hw deadtime comp activ Yes No -
09 No deadtime detection with 2 freq Yes No -
10 Detect Ls with LsBlock method Yes No -
11 MotID adaption of magnetizing current Yes No -
12 MotID adaption of main reactance Yes No -
13 MotID switch off saturation curve optim. Yes No -
14 MotID saturation curve optim. all framesizes Yes No -
15 MotID saturation curve optim. big frame-
sizes
Yes No -
p1910 Select motor data identification extended / Sel.mot.data ident
CU240E Access level: 2 P-Group: Motor identification Data type: Unsigned16
Quick comm. NO Active: NO Data set: -
Can be changed: T
Min Max Factory setting
0 23 0
