Parameters
List of Parameters
1-280
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Performs calculations necessary for optimized motor operation.
After completion of calculation, P3900 and P0010 (parameter groups for commissioning) are automatically reset to
their original value 0.
Values: 0: No quick commissioning
1: End quick commissioning with factory reset
2: End quick commissioning
3: End quick commissioning only for motor data
10: Accept safety changes (only on safety CU)
11: Cancel safety changes (only on safety CU)
Dependency: Changeable only when P0010 = 1 (quick commissioning).
Note: P3900 = 1 :
When setting 1 is selected, only the parameter settings carried out via the commissioning menu "Quick commis-
sioning", are retained; all other parameter changes, including the I/O settings, are lost.
Motor calculations are also performed.
P3900 = 2 :
When setting 2 is selected, only those parameters, which depend on the parameters in the commissioning menu
"Quick commissioning" (P0010 = 1) are calculated.
The I/O settings are also reset to default and the motor calculations performed.
P3900 = 3 :
When setting 3 is selected, only the motor and controller calculations are performed.
Exiting quick commissioning with this setting saves time (for example, if only motor rating plate data have been
changed).
Calculates a variety of motor parameters, overwriting previous values. These include P0344 (motor weight), P0350
(demagnetization time), P2000 (reference frequency), P2002 (reference current).
When transferring parameter p3900, the frequency inverter uses its processor to carry-out internal calculations.
Communications - both via USS as well as via the Fieldbus - are interrupted for the time that it takes to make these
calculations. This can result in the following error messages at the connected SIMATIC S7 control (communications
via fieldbus):
• Parameter fault 30
• Drive fault 70
• Drive fault 75
When using STARTER (USS) to commission the drive system, data cannot be entered while these calculations are
being made.
The faults can be acknowledged as soon as the calculations have been completed in the frequency inverter. These
calculations can take up to one minute to complete.
p3900 End of quick commissioning / Quick commiss. end
CU240E
CU240S
CU240S DP
CU240S PN
Access level: 1 P-Group: Safety Integrated Data type: Unsigned16
Quick comm. YES Active: NO Data set: -
Can be changed: C
Min Max Factory setting
0 11 0
