List of Parameters
Parameters
1-215
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Displays reverse config data display communication.
Index: [0] = FB diagnosis 0
[1] = FB diagnosis 1
[2] = FB diagnosis 2
[3] = FB diagnosis 3
[4] = FB diagnosis 4
[5] = FB diagnosis 5
[6] = FB diagnosis 6
[7] = FB diagnosis 7
[8] = FB diagnosis 8
[9] = FB diagnosis 9
[10] = FB diagnosis 10
[11] = FB diagnosis 11
[12] = FB diagnosis 12
[13] = FB diagnosis 13
[14] = FB diagnosis 14
[15] = FB diagnosis 15
Index: [0] = messages txd
[1] = valid messages rxd
[2] = crc errors
[3] = stx errors
[4] = reconfigurations
Description: Displays control word 1 received from Fieldbus.
Note: If P0700 = 6 (PROFIBUS) then P810 must be set to 2090.15 for correct operation.
This will not be cleared automatically when P0700 is no longer equal to 6.
r2058[0...15] FB rev config / FB rev config
CU240S DP
CU240S DP-F
Access level: 3 P-Group: Communications Data type: Unsigned16
Unit: - Data set: -
r2059[0...4] CO: Displays SOL link stats for Sol Master. / Disp SOL stats
CU240S DP
CU240S DP-F
CU240S PN
Access level: 4 P-Group: Communications Data type: Unsigned16
Unit: - Data set: -
r2090.0...15 BO: Control word 1 from Fieldbus / CtrlWd1 <- FB
CU240S DP
CU240S DP-F
CU240S PN
Access level: 3 P-Group: Communications Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 ON/OFF1 Yes No -
01 OFF2: Electrical stop No Yes -
02 OFF3: Fast stop No Yes -
03 Pulse enable Yes No -
04 RFG enable Yes No -
05 RFG start Yes No -
06 Setpoint enable Yes No -
07 Fault acknowledge Yes No -
08 JOG right Yes No -
09 JOG left Yes No -
10 Control from PLC Yes No -
11 Reverse (setpoint inversion) Yes No -
13 Motor potentiometer MOP up Yes No -
14 Motor potentiometer MOP down Yes No -
15 CDS Bit 0 (Hand/Auto) Yes No -
