List of Parameters
Parameters
1-125
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Defines source of JOG left when P0719 = 0 (Auto selection of command/setpoint source).
Dependency: When Standard Telegram selected (P0700 = 6, P0922 = Standard Telegram), parameter cannot be changed.
Description: While JOG Enable is '0' Jogging (p1056 and p1055) is disabled. When '1' Jogging is enabled.
Description: Jogging increases the motor speed by small amounts.
The JOG mode allows the operator to perform a specific number of revolutions and position the rotor manually.
The JOG buttons on OP use a non-latching switch on one of the digital inputs to control the motor speed. While the
JOG button is pressed, parameter P1058 determines the frequency at which the inverter will run.
The motor speed is increased as long as 'JOG left' or 'JOG right' are selected and until the left or right JOG fre-
quency is reached.
Dependency: P1060 and P1061 set up and down ramp times respectively for jogging.
Rounding times (P1130 - P1133), rounding type (P1134) and P2167 will also have influence on the JOG ramp.
Description: While JOG left is selected, this parameter determines the frequency at which the inverter will run.
Dependency: P1060 and P1061 set up and down ramp times respectively for jogging.
p1056[0...2] BI: Enable JOG left / Enable JOG <-
CU240S PN Access level: 3 P-Group: Commands Data type: Unsigned32
Quick comm. NO Active: NO Data set: CDS
Can be changed: T
Min Max Factory setting
- - 8890.9
p1057 JOG Enable / JOG Enable
Access level: 3 P-Group: Commands Data type: Unsigned16
Quick comm. NO Active: NO Data set: -
Can be changed: T
Min Max Factory setting
0000 bin 0001 bin 0001 bin
p1058[0...2] JOG frequency / JOG frequency
Access level: 2 P-Group: Setpoints Data type: Floating Point
Quick comm. NO Active: YES Data set: DDS
Can be changed: U, T
Min Max Factory setting
0.00 [Hz] 650.00 [Hz] 5.00 [Hz]
p1059[0...2] JOG frequency left / JOG frequency <-
Access level: 2 P-Group: Setpoints Data type: Floating Point
Quick comm. NO Active: YES Data set: DDS
Can be changed: U, T
Min Max Factory setting
0.00 [Hz] 650.00 [Hz] 5.00 [Hz]
