Siemens CU240S DP-F Parameter Manual

List of Parameters
Parameters
1-63
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Displays iron temperature of motor mass model.
Description: Displays stator winding temperature of motor mass model.
Description: Displays rotor winding temperature of motor mass model.
Description: Defines motor overload current limit in [%] relative to P0305 (rated motor current).
Dependency: Limited to maximum inverter current or to 400 % of rated motor current (P0305), whichever is the lower.
Note: Changes to P640 will be effective only after the next off state.
See function diagram for current limitation.
Description: Selects digital command source.
Values: 0: Factory default setting
1: BOP (keypad)
2: Terminal
4: USS on RS232
5: USS on RS485
Dependency: Changing this parameter sets (to default) all settings on item selected. These are the following parameters:
P0701, ... (function of DI), P0731, P0732, P0733, P0800, P0801, P0840, P0842, P0844, P0845, P0848, P0849,
P0852, P1020, P1021, P1022, P1023, P1035, P1036, P1055, P1056, P1074, P1110, P1113, P1124, P1140,
P1141, P1142, P1230, P1477, P1501, P2103, P2104, P2106, P2200, P2220, P2221, P2222, P2223, P2226,
P2228, P2235, P2236
Caution: Be aware, by changing of parameter P0700 all BI parameters are reset to the default value.
r0631[0...2] CO: Stator iron temperature / Stat.iron temp
Access level: 4 P-Group: Motor Data type: Floating Point
Unit: [°C] Data set: DDS
r0632[0...2] CO: Stator winding temperature / Stat.wind.temp
Access level: 4 P-Group: Motor Data type: Floating Point
Unit: [°C] Data set: DDS
r0633[0...2] CO: Rotor winding temperature / Rot. wind.temp
Access level: 4 P-Group: Motor Data type: Floating Point
Unit: [°C] Data set: DDS
p0640[0...2] Motor overload factor [%] / Motor ovl fact [%]
Access level: 2 P-Group: Motor Data type: Floating Point
Quick comm. YES Active: YES Data set: DDS
Can be changed: C, U, T
Min Max Factory setting
10.0 [%] 400.0 [%] 200.0 [%]
100
p0305
p0305) 4 (r0209, min
p0640max ⋅
⋅
=
p0700[0...2] Selection of command source / Command source sel
CU240E
CU240S
Access level: 1 P-Group: Commands Data type: Unsigned16
Quick comm. YES Active: NO Data set: CDS
Can be changed: C, T
Min Max Factory setting
0 5 2
