Siemens CU240S DP-F Parameter Manual

List of Parameters
Parameters
1-13
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
1.2 List of Parameters
Product: G120, Version: 3005200, Language: eng
Description: Displays the user selected output. This value is defined in P0005.
Note: Pressing the "Fn" button on OP for 2 seconds allows the user to view the values of DC link voltage, output fre-
quency, output voltage, output current, and chosen r0000 setting (defined in P0005).
Description: Displays actual drive state.
Values: 0: Commissioning mode (P0010 != 0)
1: Drive ready
2: Drive fault active
3: Drive starting (DC-link precharging)
4: Drive running
5: Stopping (ramping down)
6: Drive inhibited
7: Safety active
8: Safety reset/commissioning
9: Safety fault active
Dependency: State 3 visible only while precharging DC link.
It is only visible when an externally powered control unit is fitted.
Description: Displays actual drive state.
Values: 0: Commissioning mode (P0010 != 0)
1: Drive ready
2: Drive fault active
3: Drive starting (DC-link precharging)
4: Drive running
5: Stopping (ramping down)
6: Drive inhibited
7: Safety active
8: Safety reset/commissioning
9: Safety fault active
Dependency: State 3 visible only while precharging DC link.
r0000 Drive display / Drive display
Access level: 1 P-Group: - Data type: Unsigned16
Unit: - Data set: -
r0002 Drive state / Drive state
CU240E
CU240S DP-F
Access level: 2 P-Group: Commands Data type: Unsigned16
Unit: - Data set: -
r0002 Drive state / Drive state
CU240S
CU240S DP
CU240S PN
Access level: 2 P-Group: Commands Data type: Unsigned16
Unit: - Data set: -
