Parameters
List of Parameters
1-268
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Defines delay time of timer 1.
P2849, P2850, P2851 are the inputs of the timer, outputs are P2852, P2853.
Dependency: P2802[0] is active level for the timer.
Description: Selects mode of timer 1.
P2849, P2850, P2851 are the inputs of the timer, outputs are P2852, P2853.
Values: 0: ON delay (seconds)
1: OFF delay (seconds)
2: ON/OFF delay (seconds)
3: Pulse generator (seconds)
10: ON delay (minutes)
11: OFF delay (minutes)
12: ON/OFF delay (minutes)
13: Pulse generator (minutes)
Dependency: P2802[0] is active level for the timer.
Description: Displays output of timer 1.
P2849, P2850, P2851 are the inputs of the timer, outputs are P2852, P2853.
Dependency: P2802[0] is active level for the timer.
Description: Displays Not-output of timer 1.
P2849, P2850, P2851 are the inputs of the timer, outputs are P2852, P2853.
Dependency: P2802[0] is active level for the timer.
p2850 Delay time of timer 1 / Delay time timer 1
Access level: 3 P-Group: Technology Data type: Floating Point
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
0.0 [s] 9999.9 [s] 0.0 [s]
p2851 Mode timer 1 / Mode timer 1
Access level: 3 P-Group: Technology Data type: Unsigned16
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
0 13 0
r2852.0 BO: Timer 1 / Timer 1
Access level: 3 P-Group: Technology Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Output of BO Yes No -
r2853.0 BO: Nout timer 1 / Nout timer 1
Access level: 3 P-Group: Technology Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Output of BO Yes No -
