Parameters
List of Parameters
1-256
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Example: P2801[3] = 2, P2801[4] = 2, P2802[3] = 3, P2802[4] = 2
FFBs will be calculated in following order:
P2802[3], P2801[3] , P2801[4], P2802[4]
Index: [0] = Enable AND 1
[1] = Enable AND 2
[2] = Enable AND 3
[3] = Enable OR 1
[4] = Enable OR 2
[5] = Enable OR 3
[6] = Enable XOR 1
[7] = Enable XOR 2
[8] = Enable XOR 3
[9] = Enable NOT 1
[10] = Enable NOT 2
[11] = Enable NOT 3
[12] = Enable D-FF 1
[13] = Enable D-FF 2
[14] = Enable RS-FF 1
[15] = Enable RS-FF 2
[16] = Enable RS-FF 3
Dependency: Set P2800 to 1 to enable function blocks.
All active function blocks will be calculated in every 132 ms.
Description: Free function blocks (FFB) are enabled in two steps.
1. Parameter P2800 enables all free function blocks, normally (P2800 = 1).
2. Parameters P2801 and P2802 respectively, enable each free function block individually (P2801[x] > 0 or
P2802[x] > 0).
In addition, Parameters P2801 and P2802 determine the chronological order of each function block.
The following table shows that the priority increases from left to right and from bottom to top.
Values: 0: Not Active
1: Level 1
2: Level 2
3: Level 3
p2802[0...13] Activate FFBs / Activate FFBs
Access level: 3 P-Group: Technology Data type: Unsigned16
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
0 3 0
3
2
1
0
P2802 [13] CMP 2 P2802 [12] CMP 1 P2802 [11] DIV 2 P2802 [10] DIV 1 P2802 [9] MUL 2 P2802 [8] MUL 1 P2802 [7] SUB 2 P2802 [6] SUB 1 P2802 [5] ADD 2 P2802 [4] ADD 1 P2802 [3] Timer 4 P2802 [2] Timer 3 P2802 [1] Timer 2 P2802 [0] Timer 1 P2801 [16] RS-FF 3 P2801 [15] RS-FF 2 P2801 [14] RS-FF 1 P2801 [13] D-FF 2 P2801 [12] D-FF 1 P2801 [11] NOT 3 P2801 [10] NOT 2 P2801 [9] NOT 1 P2801 [8] XOR 3 P2801 [7] XOR 2 P2801 [6] XOR 1 P2801 [5] OR 3 P2801 [4] OR 2 P2801 [3] OR 1 P2801 [2] AND 3 P2801 [1] AND 2 P2801 [0] AND 1
Level
Level
Level
Inactive
low
high
Priority 1
Priority 2
low
