Parameters
List of Parameters
1-236
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Monitoring word 1 which indicates the state of monitor functions.
Each bit represents one monitor function.
Description: Monitoring word 2 which indicates the state of monitor functions.
Each bit represents one monitor function.
r2197.0...12 CO/BO: Monitoring word 1 / Monitor Wd1
PM250
PM260
Access level: 2 P-Group: Messages Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 f_act <= P1080 (f_min) Yes No -
01 f_act <= P2155 (f_1) Yes No -
02 f_act > P2155 (f_1) Yes No -
03 f_act > zero Yes No -
04 f_act >= setp. (f_set) Yes No -
05 f_act <= P2167 (f_off) Yes No -
06 f_act >= P1082 (f_max) Yes No -
07 f_act == setp. (f_set) Yes No -
08 Act. current r0068 <= P2170 Yes No -
11 Load missing Yes No -
12 f_act > P1082 with delay Yes No -
r2198.0...12 CO/BO: Monitoring word 2 / Monitor Wd2
Access level: 2 P-Group: Messages Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 |f_act| <= P2157 (f_2) Yes No -
01 |f_act| > P2157 (f_2) Yes No -
02 |f_act| <= P2159 (f_3) Yes No -
03 |f_act| > P2159 (f_3) Yes No -
04 |f_set| < P2161 (f_min_set) Yes No -
05 f_set > 0 Yes No -
06 Motor blocked Yes No -
07 Motor pulled out Yes No -
08 | I_act r0068 | < P2170 Yes No -
09 | m_act | > P2174 & setpoint reached Yes No -
10 | m_act | > P2174 Yes No -
11 Belt failure warning Yes No -
12 Belt failure trip Yes No -
