Page #271 background image
List of Parameters
Parameters
1-271
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Displays output of timer 3.
P2859, P2860, P2861 are the inputs of the timer, outputs are P2862, P2863.
Dependency: P2802[2] is active level for the timer.
Description: Displays Not-output of timer 3.
P2859, P2860, P2861 are the inputs of the timer, outputs are P2862, P2863.
Dependency: P2802[2] is active level for the timer.
Description: Define input signal of timer 4.
P2864, P2865, P2866 are the inputs of the timer, outputs are P2867, P2868.
Dependency: P2802[3] is active level for the timer.
Description: Defines delay time of timer 4.
P2864, P2865, P2866 are the inputs of the timer, outputs are P2867, P2868.
Dependency: P2802[3] is active level for the timer.
r2862.0 BO: Timer 3 / Timer 3
Access level: 3 P-Group: Technology Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Output of BO Yes No -
r2863.0 BO: Nout timer 3 / Nout timer 3
Access level: 3 P-Group: Technology Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Output of BO Yes No -
p2864 BI: Timer 4 / Timer 4
Access level: 3 P-Group: Technology Data type: Unsigned32
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
- - 0
p2865 Delay time of timer 4 / Delay time timer 4
Access level: 3 P-Group: Technology Data type: Floating Point
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
0.0 [s] 9999.9 [s] 0.0 [s]
