Siemens CU240S DP-F Parameter Manual

Function diagrams
Vector Control
2-376
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Fig. 2-50 8000 – Analog outputs and display values
Sheet
7900 6100 6100 5200
from sheet from sheet from sheet from sheet from sheet
- 8000 -
Function diagram
87654321
8000.vsd
SINAMICS G120
02.04.2007 V3.0
Analog outputs and display values
x
y = f(x)
y
D
A
12 13
AO1
D
A
26 27
AO2
V or 0 ... 20 mA 0 ... 20 mA
%
.00 .09
1
160 ms
2 3
160 ms
4
30 ms 30 ms 30 ms
6
x
y = f(x)
y
.
.
.
.
.
.
AO1
AO2
. . .
2300
*) *)
400 ms
5
160 ms
characteristic **)
Display values Analogue outputs
Act fil rotorspeed [RPM]
r0022
r1170
Setp. after RFG [Hz]
r0021
Act. filt. freq. [Hz]
r0063
Act. frequency [Hz]
r0024
Act. outp. freq [Hz]
r0066
Act. outp freq [Hz]
r0072
Act. outp.volt [V]
r0025
Act.outp. volt [V]
r0031
Act fil torque [Nm]
r0032
Act fil. power
r0080
Act. torque [Nm]
r0027
Act. outp. cur [A]
r0026 [2]
Act. fil. Vdc [V]
r0068
Output current [A]
r0070
Act. Vdc [V]
AO
(21[0])
P0771 [2]
AO
(21[0])
P0771 [2]
Value x1:AO scal.
-99999.0 ... 99999.0 [%]
P0777 [2] (0.0)
Value y2:AO scal.
0 ... 20
P0780 [2] (20)
Value x1:AO scal.
-99999.0 ... 99999.0 [%]
P0777 [2] (0.0)
Value y2:AO scal.
0 ... 20
P0780 [2] (20)
characteristic **)
PZD signals
(0)
P0095 [10]
Reference Parameters
P2000 ... P2004
Displays PZD signals in [%] r0096.0 ... .9
*) Access level 4
**) Reference values
P2000 = Reference frequency P2001 = Reference voltage P2002 = Reference current P2004 = Reference power
6100
