Siemens CU240S DP-F Parameter Manual

Parameters
List of Parameters
1-166
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Displays filtered actual speed at speed controller input.
Description: Sets time constant of PT1 filter to filter the speed deviation of speed controller in operation mode SLVC (sensorless
vector control).
Description: Enters gain of speed controller.
Description: Enters integral time of speed controller.
Description: Enters gain of speed controller for sensorless vector control (SLVC).
Description: Enters integral time of speed controller for sensorless vector control (SLVC).
r1445 CO: Act. filtered frequency / Act. filt freq
Access level: 4 P-Group: Closed-loop control Data type: Floating Point
Unit: [Hz] Data set: -
p1452[0...2] Filter time for act.speed (SLVC) / Act.spd.filt. SLVC
Access level: 2 P-Group: Closed-loop control Data type: Unsigned16
Quick comm. NO Active: YES Data set: DDS
Can be changed: U, T
Min Max Factory setting
2 [ms] 32000 [ms] 2 [ms]
p1460[0...2] Gain speed controller / Gain of n-ctrl.
CU240S
CU240S DP
CU240S DP-F
CU240S PN
Access level: 2 P-Group: Closed-loop control Data type: Floating Point
Quick comm. NO Active: YES Data set: DDS
Can be changed: U, T
Min Max Factory setting
0.0 2000.0 3.0
p1462[0...2] Integral time speed controller / Tn of n-ctrl.
CU240S
CU240S DP
CU240S DP-F
CU240S PN
Access level: 2 P-Group: Closed-loop control Data type: Unsigned16
Quick comm. NO Active: YES Data set: DDS
Can be changed: U, T
Min Max Factory setting
25 [ms] 32001 [ms] 400 [ms]
p1470[0...2] Gain speed controller (SLVC) / Gain n-ctrl (SLVC)
Access level: 2 P-Group: Closed-loop control Data type: Floating Point
Quick comm. NO Active: YES Data set: DDS
Can be changed: U, T
Min Max Factory setting
0.0 2000.0 3.0
p1472[0...2] Integral time n-ctrl. (SLVC) / Tn of n-ctrl. SLVC
Access level: 2 P-Group: Closed-loop control Data type: Unsigned16
Quick comm. NO Active: YES Data set: DDS
Can be changed: U, T
Min Max Factory setting
25 [ms] 32001 [ms] 400 [ms]
