Siemens CU240S DP-F Parameter Manual

Parameters
List of Parameters
1-264
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Displays output of D-FlipFlop 1, inputs are defined in P2834[0], P2834[1], P2834[2], P2834[3]
Dependency: P2801[12] is active level for the D-FlipFlop.
Description: Displays Not-output of D-FlipFlop 1, inputs are defined in P2834[0], P2834[1], P2834[2], P2834[3]
Dependency: P2801[12] is active level for the D-FlipFlop.
Description: P2837[0], P2837[1], P2837[2], P2837[3] define inputs of D-FlipFlop 2, outputs are P2838, 2839.
Index: [0] = Binector input: Set
[1] = Binector input: D input
[2] = Binector input: Store pulse
[3] = Binector input: Reset
Dependency: P2801[13] is active level for the D-FlipFlop.
Description: Displays output of D-FlipFlop 2, inputs are defined in P2837[0], P2837[1], P2837[2], P2837[3]
Dependency: P2801[13] is active level for the D-FlipFlop.
Description: Displays Not-output of D-FlipFlop 2, inputs are defined in P2837[0], P2837[1], P2837[2], P2837[3]
Dependency: P2801[13] is active level for the D-FlipFlop.
r2835.0 BO: Q D-FF 1 / Q D-FF 1
Access level: 3 P-Group: Technology Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Output of BO Yes No -
r2836.0 BO: NOT-Q D-FF 1 / NOT-Q D-FF 1
Access level: 3 P-Group: Technology Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Output of BO Yes No -
p2837[0...3] BI: D-FF 2 / D-FF 2
Access level: 3 P-Group: Technology Data type: Unsigned32
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
- - 0
r2838.0 BO: Q D-FF 2 / Q D-FF 2
Access level: 3 P-Group: Technology Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Output of BO Yes No -
r2839.0 BO: NOT-Q D-FF 2 / NOT-Q D-FF 2
Access level: 3 P-Group: Technology Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Output of BO Yes No -
