List of Parameters
Parameters
1-57
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Enables selection of various pulse types. Only bits 04 and 05 are used.
Description: Specifies the number of encoder pulses per revolution.
Note: The encoder resolution (pulses per revolution P0408) which may be entered will be limited by the max. pulse fre-
quency of the encoder circuits (f_max = 300 kHz).
The following equation calculates the encoder frequency depending on the encoder resoulution and the rotational
speed (rpm). The encoder frequency has to be less than the max. pulse frequency:
Description: Reverses internal direction sense of the encoder signal. This does the same thing as switching the ENC_A and
ENC_B signals.
Values: 0: Encoder Normal Rotation
1: Encoder Reverse Rotation
p0405[0...2] Enables selection of pulse types / Enables pulse type
CU240S
CU240S DP
CU240S DP-F
CU240S PN
Access level: 2 P-Group: Converter Data type: Unsigned16
Quick comm. NO Active: YES Data set: DDS
Can be changed: T
Min Max Factory setting
- - 0000 bin
Bit field: Bit Signal name 1 signal 0 signal FP
00 not used Yes No -
01 not used Yes No -
02 not used Yes No -
03 not used Yes No -
04 invert Z-pulse Yes No -
05 Z-pulse = Z-pulse & A-pulse & B-pulse Yes No -
06 not used Yes No -
07 not used Yes No -
08 not used Yes No -
p0408[0...2] Encoder pulses per revolution / Enc pulses per rev
CU240S
CU240S DP
CU240S DP-F
CU240S PN
Access level: 2 P-Group: Encoder Data type: Unsigned16
Quick comm. YES Active: YES Data set: DDS
Can be changed: C, T
Min Max Factory setting
2 20000 1024
p0408 x rpm
f
max
> f =
60
p0410[0...2] Reverses internal direction sense / Rev dir sense
CU240S
CU240S DP
CU240S DP-F
CU240S PN
Access level: 2 P-Group: Encoder Data type: Unsigned16
Quick comm. NO Active: YES Data set: DDS
Can be changed: T
Min Max Factory setting
0 1 0
