List of Parameters
Parameters
1-89
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Defines function of the analog output.
Index: [0] = Analog output 0 (AO0)
[1] = Analog output 1 (AO1)
Description: Defines smoothing time [ms] for analog output signal.
This parameter enables smoothing for AO using a PT1 filter.
Index: [0] = Analog output 0 (AO0)
[1] = Analog output 1 (AO1)
Dependency: P0773 = 0: Deactivates filter.
Description: Shows value of analog output after filtering and scaling.
Index: [0] = Analog output 0 (AO0)
[1] = Analog output 1 (AO1)
Description: Decides if the absolute value of the analog output is used. If enabled, this parameter will take the absolute value to
be outputed. If the value was originally negative then the corresponding bit in r0785 is set, otherwise it is cleared.
Index: [0] = Analog output 0 (AO0)
[1] = Analog output 1 (AO1)
p0771[0...1] CI: AO / AO
Access level: 2 P-Group: Terminals Data type: Unsigned32
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
- - 21[0]
p0773[0...1] Smooth time AO / Smooth time AO
Access level: 2 P-Group: Terminals Data type: Unsigned16
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
0 [ms] 1000 [ms] 2 [ms]
r0774[0...1] Act. AO value [V] or [mA] / Act.AO val.[V/mA]
Access level: 2 P-Group: Terminals Data type: Floating Point
Unit: - Data set: -
p0775[0...1] Permit absolute value / Enable ab. value
Access level: 2 P-Group: Terminals Data type: Unsigned16
Quick comm. NO Active: NO Data set: -
Can be changed: T
Min Max Factory setting
0 65535 0
