Parameters
List of Parameters
1-34
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Displays hardware features of power module.
Note: Parameter r0204 = 0 indicates that no power module has been identified.
Description: Displays hardware features of power module.
Note: Parameter r0204 = 0 indicates that no power module has been identified.
Description: Selects inverter application.
The inverter and motor requirements are determined by the speed range and torque requirements of the load. The
relationship between speed and torque for different loads (high overloads or light overloads) is shown in the follow-
ing figure:
r0204 Power module features / Pmodule features
PM240 Access level: 3 P-Group: Converter Data type: Unsigned32
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 DC input voltage Yes No -
01 RFI filter Yes No -
02 Active Line Module Yes No -
03 SLM Yes No -
04 BLM with thryistor Yes No -
05 BLM with Diode Yes No -
06 Water Cooled Yes No -
12 Safe Brake Yes No -
13 Saftey Enabled Yes No -
14 Integrated Output Filter Yes No -
r0204 Power module features / Pmodule features
PM250
PM260
Access level: 3 P-Group: Converter Data type: Unsigned32
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 DC input voltage Yes No -
01 RFI filter Yes No -
02 Active Line Module Yes No -
03 SLM Yes No -
04 BLM with thryistor Yes No -
05 BLM with Diode Yes No -
06 Water Cooled Yes No -
07 F3E Powerstack Yes No -
12 Safe Brake Yes No -
13 Saftey Enabled Yes No -
14 Integrated Output Filter Yes No -
p0205 Inverter application / Inverter appl.
Access level: 3 P-Group: Converter Data type: Unsigned16
Quick comm. YES Active: NO Data set: -
Can be changed: C
Min Max Factory setting
0 1 0
