Siemens CU240S DP-F Parameter Manual

Technology Functions
Function diagrams
2-343
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Fig. 2-21 4100 – Monitoring
Monitor Wd2
r2198 r2198
Monitor Wd1
r2197 r2197
Act StatWd2
r0053 r0053
Monitor Wd1
r2197 r2197
Act StatWd2
r0053 r0053
Monitor Wd1
r2197 r2197
Act StatWd2
r0053 r0053
- 4100 -
Function diagram
87654321
4100_SW21.vsd
Technology Functions
SINAMICS G120
02.04.2007 V3.0
Monitoring
0
1
f_act r0063
T0
f_act r0063
0
1
{
.1 .2 .5 .0
0T
0
1
I_act r0068
.3
0T
0
1
I_act r0068
.8 .8
|f_act| >= P2167 (f_off) |f_act| > P1080 (f_min) |I_act| >= P2170 (I_thresh) |I_act| < P2170
no Brake selected
Brake closed
(on ramp down)
SwOff freq. f_off
0.00 ... 10.00 [Hz] P2167.DDS (1.00)
Delay time T_off
0 ... 10000 [ms]
P2168.DDS (10)
Min. frequency
0.00 ... 650.00 [Hz]
P1080.DDS (0.00)
Hyst. freq. f_hys
0.00 ... 10.00 [Hz] P2150.DDS (3.00)
Tconst. speed filt
0 ... 1000 [ms]
P2153.DDS (5)
Delay time current
0 ... 10000 [ms]
P2171.DDS (10)
Threshold current
0.0 ... 400.0 [%]
P2170.DDS (100.0)
Delay time current
0 ... 10000 [ms]
P2171.DDS (10)
Threshold current
0.0 ... 400.0 [%]
P2170.DDS (100.0)
