Siemens CU240S DP-F Parameter Manual

Internal Setpoint Source
Function diagrams
2-341
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Fig. 2-20 3400 – PID Motor Potentiometer (PID-MOP)
- 3400 -
Function diagram
87654321
3400_PIDMOP.vsd
Internal Setpoint Source
SINAMICS G120
02.04.2007 V3.0
PID Motor Potentiometer (PID-MOP)
0 1 1 0 1 1
0 0
-1
0 1
PID-MOP output start value control
PID-MOP
RFG
(0)
Setp. auto/manu
P2241.CDS
Setp. of PID-MOP
-200.00 ... 200.00 [%]
P2240.DDS ( 10.00)
r2250
PMOP outp. setp [%]
(19.13)
PID-MOP (UP)
P2235.CDS
(19.14)
PID-MOP (DWN)
P2236.CDS
PID-MOP mode.
- ... -
P2231.DDS (0)
Inhib. PID-MOD rev
0 ... 1
P2232 (1)
1 0
PMOP auto setpoint
(0)
P2242.CDS
(0)
PMOP acc RFG setpo
P2243.CDS
PMOP RFG setpoint
(0)
P2244.CDS
MOP ramp-up time
0.00 ... 1000.00 [s]
P1047.DDS (10.00)
MOP rampdown time
0.00 ... 1000.00 [s]
P1048.DDS (10.00)
r2245
PMOP RFG input [%]
%
Max. frequency
0.00 ... 650.00 [Hz] P1082.DDS (50.00)
Rated motor freq.
12.00 ... 650.00 [Hz]
P0310.DDS (50.00)
100 %
Bit 00 = 1: Setpoint store active Bit 01 = 1: No On-state for MOP necessary
