Siemens CU240S DP-F Parameter Manual

Function diagrams
Internal Setpoint Source
2-338
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Fig. 2-17 3210 – Fixed Frequency (FF) Binary Selection (P1016 = 2)
- 3210 -
Function diagram
87654321
3210_FF.vsd
Internal Setpoint Source
SINAMICS G120
02.04.2007 V3.0
Fixed Frequency (FF) Binary Selection (P1016 = 2)
0 0 0 1
0 1 0 1
0 1 1 0 1 1 1 1
. . .
. . .
. . . . . .
0 1 0 0
(722.3)
FF sel. Bit 0
P1020.CDS
(722.4)
FF sel. Bit 1
P1021.CDS
(722.5)
FF sel. Bit 2
P1022.CDS
(722.6)
FF sel. Bit 3
P1023.CDS
FF Status
r1025
r1024
Act. FF [Hz]
Fixed frequency 1
-650.00 ... 650.00 [Hz]
P1001.DDS ( 0.00)
Fixed frequency 4
-650.00 ... 650.00 [Hz]
P1004.DDS ( 15.00)
Fixed frequency 5
-650.00 ... 650.00 [Hz]
P1005.DDS (20.00)
Fixed frequency 6
-650.00 ... 650.00 [Hz]
P1006.DDS (25.00)
Fixed frequency 15
-650.00 ... 650.00 [Hz]
P1015.DDS (65.00)
