List of Parameters
Parameters
1-297
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Confirm checksum of the safety parameters.
Note: Enter the reading of r9798 or r9898 into p9899 once the safety parametrisation is complete.
Description: PROFInet name of station.
Displays each character in a separate index.
Description: PROFInet IP address.
Displays e.g. 255.255.255.1 as
p61001[0] : 255
p61001[1] : 255
p61001[2] : 255
p61001[3] : 1
Description: PROFInet MAC address.
Displays e.g. 5F-23-AD-F4-5A-22 as
p61002[0] : 5F
p61002[1] : 23
p61002[2] : AD
p61002[3] : F4
p61002[4] : 5A
p61002[5] : 22
Description: PROFInet default gateway.
Displays e.g. 192.168.2.1 as
p61003[0] : 192
p61003[1] : 168
p61003[2] : 2
p61003[3] : 1
p9899 SI parameter checksum / SI checksum
CU240S DP-F Access level: 3 P-Group: Safety Integrated Data type: Unsigned16
Quick comm. NO Active: NO Data set: -
Can be changed: -
Min Max Factory setting
0000 hex FFFF hex 8AFD hex
r61000[0...239] PROFInet Name Of Station / PN name of station
CU240S PN Access level: 3 P-Group: Communications Data type: Unsigned16
Unit: - Data set: -
r61001[0...3] PROFInet IP Of Station / PN IP adr
CU240S PN Access level: 3 P-Group: Communications Data type: Unsigned16
Unit: - Data set: -
r61002[0...5] PROFInet MAC Of Station / PN MAC adr
CU240S PN Access level: 3 P-Group: Communications Data type: Unsigned16
Unit: - Data set: -
r61003[0...3] PROFInet Default Gateway Of Station / PN Gateway adr
CU240S PN Access level: 3 P-Group: Communications Data type: Unsigned16
Unit: - Data set: -
