Parameters
List of Parameters
1-294
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Confirm checksum of the P1 safety parameters. The correct value has to be entered before leaving the safety com-
missioning with p3900 = 10.
Only if r9798, r9898, p9799 and p9899 are all identical, the commissioning can be finished.
Note: Enter the reading of r9798 or r9898 into p9799 once no more safety parameters need to be changed.
Description: Double of parameter p9601. See there.
Note: On non-safety hardware units, p9801 is zero by default.
Description: Double of parameter p9602. See there.
Values: 0: Disable monitoring of safe brake control
1: Enable monitoring of safe brake control
Description: Double of parameter p9603. See there.
p9799 SI parameter checksum / SI checksum
CU240S DP-F Access level: 3 P-Group: Safety Integrated Data type: Unsigned16
Quick comm. NO Active: NO Data set: -
Can be changed: -
Min Max Factory setting
0000 hex FFFF hex 8AFD hex
p9801 SI enable parameter / SI enable param.
CU240S DP-F Access level: 3 P-Group: Safety Integrated Data type: Unsigned16
Quick comm. NO Active: NO Data set: -
Can be changed: -
Min Max Factory setting
- - 0010 bin
Bit field: Bit Signal name 1 signal 0 signal FP
00 reserved Yes No -
01 Enable forced dynamisation (self test) after
STO
Yes No -
p9802 SI enable safe brake monitoring / SI brake mon. ena
CU240S DP-F Access level: 3 P-Group: Safety Integrated Data type: Unsigned16
Quick comm. NO Active: NO Data set: -
Can be changed: -
Min Max Factory setting
0 1 0
p9803 SI Selection of Safety Source / SI Source select
CU240S DP-F Access level: 3 P-Group: Safety Integrated Data type: Unsigned16
Quick comm. NO Active: NO Data set: -
Can be changed: -
Min Max Factory setting
- - 0000 bin
Bit field: Bit Signal name 1 signal 0 signal FP
07 STO, SS1, SLS activated via PROFIsafe Yes No -
