Parameters
List of Parameters
1-24
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Displays first active status word of inverter (bit format) and can be used to diagnose inverter status.
Dependency: r0052 Bit03 "Drive fault active": Output of Bit3 (Fault) will be inverted on digital output (Low = Fault, High = No
Fault).
r0052 Bit08 "Deviation setpoint / act. value" ==> see parameter P2164
r0052 Bit10 "f_act >= P1082 (f_max)" ==> see parameter P1082
r0052 Bit12 "Motor holding brake active" ==> see parameter P1215
Description: Displays second status word of inverter (in bit format).
Notice: r0053 Bit00 "DC brake active" ==> see parameter P1233
r0053 Bit01 "f_act > P2167 (f_off)" ==> see parameter P2167
r0053 Bit02 "f_act > P1080 (f_min)" ==> see parameter P1080
r0053 Bit03 "Act. current r0027 >= P2170" ==> see parameter P2170
r0053 Bit04 "f_act > P2155 (f_1)" ==> see parameter P2155
r0053 Bit05 "f_act <= P2155 (f_1)" ==> see parameter P2155
r0053 Bit06 "f_act >= setpoint (f_set)" ==> see parameter P2150
r0053 Bit07 "Vdc_act r0026 < P2172" ==> see parameter P2172
r0053 Bit08 "Vdc_act r0026 > P2172" ==> see parameter P2172
r0052.0...15 CO/BO: Act. status word 1 / Act StatWd1
Access level: 2 P-Group: Commands Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Drive ready Yes No -
01 Drive ready to run Yes No -
02 Drive running Yes No -
03 Drive fault active Yes No -
04 OFF2 active No Yes -
05 OFF3 active No Yes -
06 ON inhibit active Yes No -
07 Drive warning active Yes No -
08 Deviation setpoint / act. value No Yes -
09 PZD control Yes No -
10 f_act >= P1082 (f_max) Yes No -
11 Warning: Motor current/torque limit No Yes -
12 Brake open Yes No -
13 Motor overload No Yes -
14 Motor runs right Yes No -
15 Inverter overload No Yes -
r0053.0...15 CO/BO: Act. status word 2 / Act StatWd2
PM240 Access level: 2 P-Group: Commands Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 DC brake active Yes No -
01 f_act > P2167 (f_off) Yes No -
02 f_act > P1080 (f_min) Yes No -
03 Act. current r0027 >= P2170 Yes No -
04 f_act > P2155 (f_1) Yes No -
05 f_act <= P2155 (f_1) Yes No -
06 f_act >= setpoint (f_set) Yes No -
07 Vdc_act r0026< P2172 Yes No -
08 Vdc_act r0026 > P2172 Yes No -
09 Ramping finished Yes No -
10 PID output r2294 == P2292 (PID_min) Yes No -
11 PID output r2294 == P2291 (PID_max) Yes No -
14 Download Dataset 0 from AOP Yes No -
15 Download Dataset 1 from AOP Yes No -
