Parameters
List of Parameters
1-90
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Defines type of analog output.
Values: 0: Current output
1: Voltage output
Index: [0] = Analog output 0 (AO0)
[1] = Analog output 1 (AO1)
Note: Analog Output 0 can be switched to a voltage output with a range 0...10 V.
Analog Output 1 is only a current output. By connecting an external resistor of 500 Ohm to the terminals a voltage
output with a range of 0...10 V can be created.
Description: Defines x1 output characteristic in [%].
Scaling block is responsible for adjustment of output value defined in P0771 (AO connector input).
x1 is the first value of the two pairs of variants x1/y1 and x2/y2 which determine the straight line. The two points P1
(x1, y1) and P2 (x2, y2) can be chosen freely.
Index: [0] = Analog output 0 (AO0)
[1] = Analog output 1 (AO1)
Dependency: Affects P2000 to P2003 (referency frequency, voltage, current or torque) depending on which setpoint is to be gen-
erated.
Description: Defines y1 of output characteristic.
Index: [0] = Analog output 0 (AO0)
[1] = Analog output 1 (AO1)
Description: Defines x2 of output characteristic in [%].
Index: [0] = Analog output 0 (AO0)
[1] = Analog output 1 (AO1)
Dependency: Affects P2000 to P2003 (referency frequency, voltage, current or torque) depending on which setpoint is to be gen-
erated.
p0776[0...1] Type of AO / Type of AO
Access level: 2 P-Group: Terminals Data type: Unsigned16
Quick comm. NO Active: NO Data set: -
Can be changed: T
Min Max Factory setting
0 1 0
p0777[0...1] Value x1 of AO scaling / Value x1:AO scal.
Access level: 2 P-Group: Terminals Data type: Floating Point
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
-99999.0 [%] 99999.0 [%] 0.0 [%]
p0778[0...1] Value y1 of AO scaling / Value y1:AO scal.
Access level: 2 P-Group: Terminals Data type: Floating Point
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
0 20 0
p0779[0...1] Value x2 of AO scaling / Value x2:AO scal.
Access level: 2 P-Group: Terminals Data type: Floating Point
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
-99999.0 [%] 99999.0 [%] 100.0 [%]
