List of Parameters
Parameters
1-119
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Defines origin of fixed frequency selection.
Dependency: Accessible only if P0701 - P070x = 99 (function of digital inputs = BICO)
When Standard Telegram 350 and PROFIBUS selected (P0700 = 6, P0922 = 350), parameter cannot be changed.
Description: Defines origin of fixed frequency selection.
Dependency: Accessible only if P0701 - P070x = 99 (function of digital inputs = BICO)
When Standard Telegram 350 and PROFIBUS selected (P0700 = 6, P0922 = 350), parameter cannot be changed.
Description: Displays sum total of selected fixed frequencies.
Description: Displays the status of fixed frequencies.
Description: MOP mode specification.
Note: Defines the operation mode of the motorized potentiometer.
See P1040 (setpoint of MOP).
p1023[0...2] BI: Fixed freq. selection Bit 3 / FF sel. Bit 3
CU240E
CU240S DP-F
Access level: 3 P-Group: Commands Data type: Unsigned32
Quick comm. NO Active: NO Data set: CDS
Can be changed: T
Min Max Factory setting
- - 0
p1023[0...2] BI: Fixed freq. selection Bit 3 / FF sel. Bit 3
CU240S
CU240S DP
CU240S PN
Access level: 3 P-Group: Commands Data type: Unsigned32
Quick comm. NO Active: NO Data set: CDS
Can be changed: T
Min Max Factory setting
- - 722.6
r1024 CO: Act. fixed frequency / Act. FF
Access level: 3 P-Group: Setpoints Data type: Floating Point
Unit: [Hz] Data set: -
r1025.0 BO: Fixed frequency status / FF Status
Access level: 3 P-Group: Commands Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Status of FF Yes No -
p1031[0...2] MOP mode / MOP mode
Access level: 2 P-Group: Setpoints Data type: Unsigned16
Quick comm. NO Active: YES Data set: DDS
Can be changed: U, T
Min Max Factory setting
- - 0
Bit field: Bit Signal name 1 signal 0 signal FP
00 Setpoint store activ Yes No -
01 No On-state for MOP necessary Yes No -
