Parameters
List of Parameters
1-84
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Displays status of digital outputs (also includes inversion of digital outputs via P0748).
Dependency: Bit = 0 signal: Contacts open
Bit = 1 signal: Contacts closed
Description: Defines high and low states of relay for a given function.
Description: Displays number of analog inputs available.
Description: Displays status of analog input.
Description: Displays smoothed analog input value in volts or milliamps before the scaling block.
Index: [0] = Analog input 0 (AI0)
[1] = Analog input 1 (AI1)
r0747.0...2 CO/BO: State of digital outputs / CO/BO:State DOs
Access level: 3 P-Group: Commands Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Digital output 0 energized Yes No -
01 Digital output 1 energized Yes No -
02 Digital output 2 energized Yes No -
p0748 Invert digital outputs / Invert DOs
Access level: 3 P-Group: Commands Data type: Unsigned16
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
- - 0000 bin
Bit field: Bit Signal name 1 signal 0 signal FP
00 Invert digital output 0 Yes No -
01 Invert digital output 1 Yes No -
02 Invert digital output 2 Yes No -
r0750 Number of AIs / Number of AIs
Access level: 3 P-Group: Terminals Data type: Unsigned16
Unit: - Data set: -
r0751.0...9 CO/BO: Status word of AI / AI status Wd
Access level: 3 P-Group: Terminals Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Signal lost on AI0 Yes No -
01 Signal lost on AI1 Yes No -
08 No signal lost on AI0 Yes No -
09 No signal lost on AI1 Yes No -
r0752[0...1] Act. input of AI [V] or [mA] / Act.AI inp.[V/mA]
Access level: 2 P-Group: Terminals Data type: Floating Point
Unit: - Data set: -
