Description: Displays diagnostic information of communication.
Index: [0] = FB diagnosis 0
[1] = FB diagnosis 1
[2] = FB diagnosis 2
[3] = FB diagnosis 3
[4] = FB diagnosis 4
[5] = FB diagnosis 5
[6] = FB diagnosis 6
[7] = FB diagnosis 7
[8] = FB diagnosis 8
[9] = FB diagnosis 9
[10] = FB diagnosis 10
[11] = FB diagnosis 11
[12] = FB diagnosis 12
[13] = FB diagnosis 13
[14] = FB diagnosis 14
[15] = FB diagnosis 15
Note: Diagnose entries
2054[0]: state of PROFIBUS: 0=off, 1=baud search; 2=baud found; 3=data exchange
2054[1]: C0 master configuration info for cyclic data, combination of 5 digits pxxyy (decimal)
p : 0 no additional cyclic data (no PKW and no PROFIsafe)
1 PKW data configured (4 words input and 4 words output)
2 PROFIsafe data configured (3 words input and 3 words output)
3 PKW and PROFIsafe data configured
4..9 wrong configuration
xx: PZD input length (reference values)
yy: PZD output length (actual values)
The values for PZD input and output length (xx and yy) do not contain any additional data length.
2054[2]: count of C2 connections 0..2
2054[3]: parameter access error: internal error number
2054[4]: parameter access error: parameter number
2054[5]: parameter access error: subindex
2054[6]: remote publisher count and remote publisher ok (example: 11114, 4 publisher, each is ok)
2054[7]: address of remote publisher 1
2054[8]: address of remote publisher 2
2054[9]: address of remote publisher 3
2054[10]: address of remote publisher 4
2054[11]: empty (=0)
2054[12]: empty (=0)
2054[13]: empty (=0)
2054[14]: empty (=0)
2054[15]: empty (=0)
r2054[0...15] FB diagnosis / FB diagnosis
CU240S DP
CU240S DP-F
Access level: 3 P-Group: Communications Data type: Unsigned16
Unit: - Data set: -
