Parameters
List of Parameters
1-296
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Note: The ramp down time in p9881 is entered in seconds!
Description: Double of parameter p9682. See there.
Note: The standstill detection frequency in p9882 is entered in kHz!
Description: Double of parameter p9690. See there.
Note: The setpoint in p9890 is entered in kHz!
Description: Double of parameter p9691. See there.
Note: The tolerance in p9891 is entered in kHz!
Description: Double of parameter p9692. See there.
Values: 0: Initiate STO with braking ramp and drive fault when f > f_SLS
1: Activate braking ramp while f > f_SLS
2: Initiate STO without braking ramp and with drive fault while f
Description: Display of safety checksum for P2 parameters. The checksum changes when safety parameters for P2 are
changed (parameter range p9800 - p9892).
Note: This checksum must be identical to the value in r9798 before the safety commissioning can be finished via p3900 =
10. If r9898 differs from r9798, the safety parameters on P2 differ from the safety parameters on P1. Check the
safety parameters and correct the mistake.
The safety commissioning can always be left via p3900 = 11, thus discarding the last changes.
p9882 SI minimum frequency for standstill detection / SI min standstill
CU240S DP-F Access level: 3 P-Group: Safety Integrated Data type: Floating Point
Quick comm. NO Active: NO Data set: -
Can be changed: -
Min Max Factory setting
0.0020 [kHz] 0.0200 [kHz] 0.0050 [kHz]
p9890 SI setpoint for SLS / SI setpoint SLS
CU240S DP-F Access level: 3 P-Group: Safety Integrated Data type: Floating Point
Quick comm. NO Active: NO Data set: -
Can be changed: -
Min Max Factory setting
0.0020 [kHz] 0.3000 [kHz] 0.0100 [kHz]
p9891 SI tolerance for SLS / SI tolerance SLS
CU240S DP-F Access level: 3 P-Group: Safety Integrated Data type: Floating Point
Quick comm. NO Active: NO Data set: -
Can be changed: -
Min Max Factory setting
0.0050 [kHz] 0.303 [kHz] 0.0130 [kHz]
p9892 SI response to selecting SLS / SI SLS response
CU240S DP-F Access level: 3 P-Group: Safety Integrated Data type: Unsigned16
Quick comm. NO Active: NO Data set: -
Can be changed: -
Min Max Factory setting
0 2 1
r9898 SI display checksum / SI act. checksum
CU240S DP-F Access level: 3 P-Group: Safety Integrated Data type: Unsigned16
Unit: - Data set: -
