Siemens CU240S DP-F Parameter Manual

Parameters
List of Parameters
1-266
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Displays output of RS-FlipFlop 2, inputs are defined in P2843[0], P2843[1]
Dependency: P2801[15] is active level for the RS-FlipFlop.
Description: Displays Not-output of RS-FlipFlop 2, inputs are defined in P2843[0], P2843[1]
Dependency: P2801[15] is active level for the RS-FlipFlop.
Description: P2846[0], P2846[1] define inputs of RS-FlipFlop 3, outputs are P2847, P2848.
Index: [0] = Binector input: Set
[1] = Binector input: Reset
Dependency: P2801[16] is active level for the RS-FlipFlop.
Description: Displays output of RS-FlipFlop 3, inputs are defined in P2846[0], P2846[1]
Dependency: P2801[16] is active level for the RS-FlipFlop.
Description: Displays Not-output of RS-FlipFlop 3, inputs are defined in P2846[0], P2846[1]
Dependency: P2801[16] is active level for the RS-FlipFlop.
r2844.0 BO: Q RS-FF 2 / Q RS-FF 2
Access level: 3 P-Group: Technology Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Output of BO Yes No -
r2845.0 BO: NOT-Q RS-FF 2 / NOT-Q RS-FF 2
Access level: 3 P-Group: Technology Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Output of BO Yes No -
p2846[0...1] BI: RS-FF 3 / RS-FF 3
Access level: 3 P-Group: Technology Data type: Unsigned32
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
- - 0
r2847.0 BO: Q RS-FF 3 / Q RS-FF 3
Access level: 3 P-Group: Technology Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Output of BO Yes No -
r2848.0 BO: NOT-Q RS-FF 3 / NOT-Q RS-FF 3
Access level: 3 P-Group: Technology Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Output of BO Yes No -
