Siemens CU240S DP-F Parameter Manual

Parameters
List of Parameters
1-64
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Selects digital command source.
Values: 0: Factory default setting
1: BOP (keypad)
2: Terminal
4: USS on RS232
6: Fieldbus
Dependency: Changing this parameter sets (to default) all settings on item selected. These are the following parameters:
P0701, ... (function of DI), P0731, P0732, P0733, P0800, P0801, P0840, P0842, P0844, P0845, P0848, P0849,
P0852, P1020, P1021, P1022, P1023, P1035, P1036, P1055, P1056, P1074, P1110, P1113, P1124, P1140,
P1141, P1142, P1230, P1477, P1501, P2103, P2104, P2106, P2200, P2220, P2221, P2222, P2223, P2226,
P2228, P2235, P2236
Caution: Be aware, by changing of parameter P0700 all BI parameters are reset to the default value.
Description: Selects function of digital input 0.
Values: 0: Digital input disabled
1: ON/OFF1
2: ON reverse /OFF1
3: OFF2 - coast to standstill
4: OFF3 - quick ramp-down
9: Fault acknowledge
10: JOG right
11: JOG left
12: Reverse
13: MOP up (increase frequency)
14: MOP down (decrease frequency)
15: Fixed frequency selector bit0
16: Fixed frequency selector bit1
17: Fixed frequency selector bit2
18: Fixed frequency selector bit3
25: DC brake enable
27: Enable PID
29: External trip
33: Disable additional freq setpoint
99: Enable BICO parameterization
Dependency: Setting 99 (enable BICO parameterization) requires:
• P0700 command source or
• P0010 = 1, P3900 = 1, 2 or 3 (quick commissioning) or
• P0010 = 30, P0970 = 1 factory reset in order to reset
Note: "ON/OFF1" can only be selected for one digital input (e.g. P0700 = 2 and P0701 = 1).
Configuring DI1 with P0702 = 1 will disable DI0 by setting P0701 = 0. Only the last activated digital input serves as
a command source.
"ON/OFF1" on a digital input can be combined with "ON reverse/OFF1" on another digital input.
p0700[0...2] Selection of command source / Command source sel
CU240S DP
CU240S DP-F
CU240S PN
Access level: 1 P-Group: Commands Data type: Unsigned16
Quick comm. YES Active: NO Data set: CDS
Can be changed: C, T
Min Max Factory setting
0 6 6
p0701[0...2] Function of digital input 0 / Function of DI0
CU240E
CU240S
PM240
Access level: 2 P-Group: Commands Data type: Unsigned16
Quick comm. NO Active: NO Data set: CDS
Can be changed: T
Min Max Factory setting
0 99 1
