Bit field
For parameters with bit fields, the following information is provided about each bit:
• Bit number and signal name
• Meaning with signal states 0 and 1
• Function diagram (optional). The signal is shown on this function diagram.
Dependency
Conditions which need to be fulfilled in connection with this parameter. Also
includes special effects which can occur between this parameter and others.
Seven-segment display
The seven-segment display of the OP is structured as follows:
Visio-7-Segment Display.pdf
Fig. 1-3 Seven-segment display
1 0 3 2 5 4 7 6
9 8 11 10 13 12 15 14 Segment Bit
Segment Bit
