No. Service Type Name Value/explanation
4 get_and
_clear
Struct of Interface Counters Optional, required if the "Media Counters Attribute" is
implemented.
UINT32 In Octets Received octets
UINT32 In Ucast Packets Received Unicast packets
UINT32 In NUcast Packets Received non-Unicast packets
UINT32 In Discards Incoming packets, not processed
UINT32 In Errors Incoming packets with errors
UINT32 In Unknown Protos Incoming packets with unknown protocol
UINT32 Out Octets Sent octets
UINT32 Out Ucast Packets Sent Unicast packets
UINT32 Out NUcast packets Sent non-Unicast packets
UINT32 Out Discards Outgoing packets, not processed
UINT32 Out Errors Outgoing packets, with errors
5 get_and
_clear
Struct of Media Counters Media-speci󹪝c counters
UINT32 Alignment Errors Structure received, which does not match the num‐
ber of octets
UINT32 FCS Errors Structure received, which does not pass the FCS check
UINT32 Single Collisions Structure successfully transmitted, precisely one col‐
lision
UINT32 Multiple Collisions Structure successfully transmitted, several collisions
UINT32 SQE Test Errors Number of SQE errors
UINT32 Deferred Transmis‐
sions
First transmission attempt delayed
UINT32 Late Collisions Number of collisions that occurred delayed by 512 bit
timers to the request
UINT32 Excessive Collisions Transmission unsuccessful as a result of intensive col‐
lisions
UINT32 MAC Transmit Errors Transmission unsuccessful as a result of an internal
MAC sublayer transmission error.
UINT32 Carrier Sense Errors Times that the carrier sense condition was lost or
never asserted when attempting to transmit a frame
UINT32 Frame Too Long Structure too large
UINT32 MAC Receive Errors Transmission unsuccessful as a result of an internal
MAC sublayer receive error.
6 get, set Struct of Interface Control 
UINT16 Control Bits 
UINT16 Forced Interface
Speed

10 get String Interface_Label Interface-Label
Parameter Object, Instance Number: 401 hex
Supported services
Class • Get Attribute all Instance • Get Attribute all
• Set Attribute single
