No. Service Type Name Value/explanation
3 get, set UNIT32 Con󹪝gura‐
tion Control
1 hex:Saved values
3 hex: DHCP
4 get UNIT16 Path Size (in
WORDs)
Fixed value: 2 hex
UNIT8 Path 20 hex,
F6 hex,
24 hex,
05 hex, where 5 hex is the number of instances of F6 hex
(four physical ports plus one internal port).
5 get, set STRING Interface
Con󹪝gura‐
tion
r61000Name of Station
UNIT32 r61001IP address
6 get, set UNIT16 Host Name Host Name Length
STRING 
10 get, set UNIT8 Select ACD local OM 󹪞ash:
0:Disabled,
1:Enabled
11 get, set UNIT8 Last Con󹪞ict
Detected
local OM 󹪞ash ACD Activity
UNIT8 local OM 󹪞ash Remote MAC
UNIT8 local OM 󹪞ash ARP PDU
Link Object, Instance Number: F6 hex
Supported services
Class • Get Attribute all
• Get Attribute single
Instance • Get Attribute all
• Get Attribute single
• Set Attribute single
Class Attribute
No. Service Type Name
1 get UINT16 Revision
2 get UINT16 Max Instance
3 get UINT16 Num of Instances
Instance Attribute
No. Service Type Name Value/explanation
1 get UINT32 Interface Speed 0:link down,
10:10 Mbps,
100:100 Mbps
2 get  Interface Flags Bit 1: Link-Status
Bit 2: Duplex Mode (0: halb duplex, 1 duplex
Bit 3…5: Automatic state identi󹪝cation
Bit 6: Reset required
Bit 7: Local hardware fault (0=ok)
3 get ARRAY Physical Address r8935 Ethernet MAC address
Advanced commissioning
7.6Drive control via Ethernet/IP
