Table 7-5 Advanced settings
Number Name Factory setting
p1030[0...n] Motorized potentiometer con󹪝gu‐
ration
Con󹪝guration for the motorized potentiometer
Factory setting: 00110 bin
.00
Storage active
= 0: After the motor has been switched on, the set‐
point = p1040
= 1: After the motor has switched o󹪜, the converter
saves the setpoint.
After the motor has switched on, the setpoint = the
stored value.
.01
Automatic mode, ramp-function generator active
(1-signal via BI: p1041)
= 0: Ramp-up/ramp-down time = 0
= 1: With ramp-function generator
In manual mode (p1041 = 0), the ramp-function
generator is always active.
.02
Initial rounding active
1: With initial rounding. Using the initial rounding
function it is possible to enter very small setpoint
changes.
.03
Storage in NVRAM active
1: If bit 00 = 1, the setpoint is retained during a
power failure.
.04
Ramp-function generator always active
1: The converter also calculates the ramp-function
generator when the motor is switched o󹪜.
p1037[0...n] Motorized potentiometer, maxi‐
mum speed [rpm]
The converter limits the motorized potentiometer
output to p1037.
Factory setting: 0 rpm
After quick commissioning, the converter sets the
parameter to the appropriate value.
p1038[0...n] Motorized potentiometer, mini‐
mum speed [rpm]
The converter limits the motorized potentiometer
output to p1038.
Factory setting: 0 rpm
After quick commissioning, the converter sets the
parameter to the appropriate value.
