Parameter Description Setting
p1070[0...n] CI: Main setpoint Signal source for the main setpoint
The factory setting depends on the converter.
• With PROFINET interface: [0] 2050[1]
• Without PROFINET interface: [0] 755[0]
p1071[0...n] CI: Main setpoint scaling Signal source for scaling the main setpoint
Factory setting: 1
r1073 CO: Main setpoint active Displays the active main setpoint
p1075[0...n] CI: Supplementary setpoint Signal source for the supplementary setpoint
Factory setting: 0
p1076[0...n] CI: Supplementary setpoint scaling Signal source for scaling the supplementary set‐
point
Factory setting: 0
r1077 CO: Supplementary setpoint e󹪜ec‐
tive [rpm]
Displays the e󹪜ective supplementary setpoint. The
value shown is the additional setpoint after scaling.
Advanced commissioning
7.17Setpoints
