Limiting the output of the technology controller
Number Name Factory setting
p2290[0...n] BI: Technology controller limitation
enable
Sets the signal source to enable the technology
controller output.
The technology controller output is enabled with a
1 signal.
Factory setting: 1
p2291 CO: Technology controller maxi‐
mum limiting [%]
Sets the maximum limit of the technology control‐
ler.
Factory setting: 100
p2292 CO: Technology controller mini‐
mum limiting [%]
Sets the minimum limit of the technology control‐
ler.
Factory setting: 0
p2293 Technology controller ramp-up/
ramp-down time [s]
Sets the ramping time for the output signal of the
technology controller.
Factory setting: 1
r2294 CO: Technology controller output
signal [%]
Display and connector output for the output signal
of the technology controller.
p2295 CO: Technology controller output
scaling [%]
Sets the scaling for the output signal of the tech‐
nology controller.
Factory setting: 100
p2296[0...n] CI: Technology controller output
scaling
Sets the signal source for the scaling value of the
technology controller.
Factory setting: 2295
p2297[0...n] CI: Technology controller maxi‐
mum limiting signal source
Sets the signal source for the maximum limiting of
the technology controller.
Factory setting: 1084
p2298[0...n] CI: Technology controller mini‐
mum limiting signal source
Sets the signal source for the minimum limiting of
the technology controller.
Factory setting: 1087
p2299[0...n] CI: Technology controller limita‐
tion o󹪜set
Sets the signal source for the o󹪜set of the output
limiting of the technology controller.
Factory setting: 0
p2302 Technology controller output sig‐
nal start value [%]
Sets the start value for the output of the technology
controller.
Factory setting: 0
Adapting the actual value of the technology controller
Parameter Description Setting
p2264[0...n] CI: Technology controller actual
value
Sets the signal source for the actual value of the
technology controller.
Factory setting: 0
p2265 Technology controller actual value
󹪝lter time constant [s]
Sets the time constant for the actual value 󹪝lter
(PT1) of the technology controller.
Factory setting: 0
Advanced commissioning
7.19PID technology controller
