Siemens SINAMICS G115D - 7.20 Motor control

Parameter Description Setting
p2266 CO: Technology controller actual
value after 󹪝lter [%]
Display and connector output for the smoothed ac‐
tual value after the 󹪝lter (PT1) of the technology
controller.
p2267 Technology controller upper limit
actual value [%]
Sets the upper limit for the actual value signal of
the technology controller.
Factory setting: 100
p2268 Technology controller lower limit
actual value [%]
Sets the lower limit for the actual value signal of the
technology controller.
Factory setting: -100
p2269 Technology controller gain actual
value [%]
Sets the scaling factor for the actual value of the
technology controller.
Factory setting: 100
p2270 Technology controller actual value
function
Setting to use an arithmetic function for the actual
value signal of the technology controller.
0: Output (y) = input (x) (factory setting)
1: Root function (root from x)
2: Square function (x * x)
3: Cube function (x * x * x)
p2271 Technology controller actual value
inversion
Setting to invert the actual value signal of the tech‐
nology controller.
0: No inversion (Factory setting)
1: Inversion actual value signal
r2272 CO: Technology controller actual
value scaled [%]
Display and connector output for the scaled actual
value signal of the technology controller.
PID technology controller, 󹪝xed values (binary selection)
Parameter Description Setting
p2201[0...n]
...
p2215[0...n]
CO: Technology controller 󹪝xed val‐
ue 1 ... 15 [%]
Sets the value for 󹪝xed value 1 ... 15 of the tech‐
nology controller.
Factory setting: 10, 20, 30 ... 150
p2216[0...n] Technology controller 󹪝xed value
selection method
Sets the method to select the 󹪝xed setpoints:
1: Direct selection (factory setting)
2: Binary selection
r2224 CO: Technology controller 󹪝xed val‐
ue active [%]
Display and connector output for the selected and
active 󹪝xed value of the technology controller.
r2225.0 CO/BO: Technology controller 󹪝xed
value selection status word [%]
Display and BICO output for the status word of the
󹪝xed value selection of the technology controller.
r2229 Technology controller number ac‐
tual
Displays the number of the selected 󹪝xed setpoint
of the technology controller.
Advanced commissioning
7.19PID technology controller
SINAMICS G115D Wall Mounted distributed drive
280 Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA
