Siemens SINAMICS G115D

PID technology controller, 󹪝xed values (direct selection)
Parameter Description Setting
p2216[0...n] Technology controller 󹪝xed value
selection method
Sets the method to select the 󹪝xed setpoints:
1: Direct selection (factory setting)
2: Binary selection
p2220[0...n]
...
p2223[0...n]
BI: Technology controller 󹪝xed val‐
ue selection bit 0 ... 3
Sets the signal source to select a 󹪝xed value of the
technology controller.
Factory setting: 0
r2224 CO: Technology controller 󹪝xed val‐
ue active [%]
Display and connector output for the selected and
active 󹪝xed value of the technology controller.
r2225.0 CO/BO: Technology controller 󹪝xed
value selection status word [%]
Display and BICO output for the status word of the
󹪝xed value selection of the technology controller.
r2229 Technology controller number ac‐
tual
Displays the number of the selected 󹪝xed setpoint
of the technology controller.
PID technology controller, motorized potentiometer
Parameter Description Setting
r2231 Technology controller motorized
potentiometer setpoint memory
[%]
Displays the setpoint memory for the motorized
potentiometer of the technology controller.
p2235[0...n] BI: Technology controller motor‐
ized potentiometer, setpoint, raise
Sets the signal source to continually increase the
setpoint for the motorized potentiometer of the
technology controller.
Factory setting: 0
p2236[0...n] BI: Technology controller motor‐
ized potentiometer, setpoint, lower
Sets the signal source to continually reduce the set‐
point for the motorized potentiometer of the tech‐
nology controller.
Factory setting: 0
p2237[0...n] Technology controller motorized
potentiometer maximum value [%]
Sets the maximum value for the motorized poten‐
tiometer of the technology controller.
Factory setting: 100
p2238[0...n] Technology controller motorized
potentiometer minimum value [%]
Sets the minimum value for the motorized potenti‐
ometer of the technology controller.
Factory setting: -100
p2240[0...n] Technology controller motorized
potentiometer start value [%]
Sets the starting value for the motorized potenti‐
ometer of the technology controller.
Factory setting: 0
r2245 CO: Technology controller motor‐
ized potentiometer, setpoint be‐
fore RFG [%]
Displays the e󹪜ective setpoint in front of the inter‐
nal motorized potentiometer ramp-function gener‐
ator of the technology controller.
p2247[0...n] Technology controller motorized
potentiometer ramp-up time [s]
Sets the ramp-up time and ramp-down time for the
internal ramp-function generator for the motorized
potentiometer of the technology controller.
Factory setting: 10
p2248[0...n] Technology controller motorized
potentiometer ramp-down time [s]
r2250 CO: Technology controller motor‐
ized potentiometer, setpoint after
RFG [%]
Displays the e󹪜ective setpoint after the internal
ramp-function generator for the motorized poten‐
tiometer of the technology controller.
Advanced commissioning
7.19PID technology controller
SINAMICS G115D Wall Mounted distributed drive
Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA 281
