You have now set monitoring.
❒
Parameters
Parameters Description Setting
r0031 Torque actual value, smoothed
[Nm]
Displays the smoothed torque actual value.
p0311[0...n] Rated motor speed [rpm] Sets the rated motor speed.
Factory setting: 0
r0333[0...n] Rated motor torque [Nm] Displays the rated motor torque.
p1080[0...n] Minimum speed [rpm] Sets the lowest possible motor speed.
Factory setting: 0
p1082[0...n] Maximum speed [rpm] Sets the highest possible speed.
Factory setting: 1500
p1300[0...n] Open-loop/closed-loop control op‐
erating mode
Sets the open and closed-loop control mode.
0: U/f control with linear characteristic (factory set‐
ting)
1: U/f control with linear characteristic and FCC
2: U/f control with parabolic characteristic
3: U/f control with parameterizable characteristic
4: U/f control with linear characteristic and ECO
5: U/f control for drives requiring a precise frequen‐
cy (e.g. textiles)
6: U/f control for drives requiring a precise frequen‐
cy and FCC
7: U/f control for a parabolic characteristic and ECO
19: U/f control with independent voltage setpoint
20: Speed control (encoderless)
22: Torque control (encoderless)
p2165[0...n] Load monitoring blocking monitor‐
ing threshold, upper [rpm]
Sets the upper speed threshold of the stall moni‐
toring of the pump or fan.
Factory setting: 0
p2168[0...n] Load monitoring blocking monitor‐
ing torque threshold [Nm]
Sets the torque threshold of the stall monitoring of
the pump or fan.
Factory setting: 10000000
p2181[0...n] Load monitoring response Sets the response when evaluating the load moni‐
toring.
0: Load monitoring disabled (factory setting)
7: Pump/fan load monitoring as alarm (A07891,
A07892, A07893)
8: Pump/fan load monitoring as fault (F07894,
F07895, F07896)
Advanced commissioning
7.27Monitoring the driven load
SINAMICS G115D Wall Mounted distributed drive
Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA 333
