Figure12-53 Mounting positions for bevel gearbox B.F ange-mounted design and B.Z with housing
ange, frame sizes19-29
Additional information on the SIMOGEAR geared motor
12.3Specic data gearbox
SINAMICS G115D Wall Mounted distributed drive
Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA 545
