Figure12-58 Mounting positions for bevel gearboxes K.F 󹪞ange-mounted design and KAZ with
housing 󹪞ange, frame sizes39-109
Additional information on the SIMOGEAR geared motor
12.3Speci󹪝c data gearbox
SINAMICS G115D Wall Mounted distributed drive
