Figure12-63 Mounting positions for helical worm gearbox CF 󹪞ange-mounted design and CAZ
housing 󹪞ange, size29
Additional information on the SIMOGEAR geared motor
12.3Speci󹪝c data gearbox
SINAMICS G115D Wall Mounted distributed drive
