P
ORT
C
ONFIGURATION
3-111
Current Status:
• Link Status – Indicates if the link is up or down.
• Port Operation Status – Provides detailed information on port state.
(Displayed only when the link is up.)
• Operation speed-duplex – Shows the current speed and duplex
mode.
• Flow control type – Indicates the type of flow control currently in use.
(IEEE 802.3x, Back-Pressure or none)
CLI – This example shows the connection status for Port 5.
Configuring Interface Connections
You can use the Port Configuration or Trunk Configuration page to
enable/disable an interface, set auto-negotiation and the interface
capabilities to advertise, or manually fix the speed, duplex mode, and flow
control.
Command Attributes
• Name – Allows you to label an interface. (Range: 1-64 characters)
Console#show interfaces status ethernet 1/5 4-165
Information of Eth 1/5
Basic information:
Port type: 100TX
Mac address: 00-12-CF-12-34-61
Configuration:
Name:
Port admin: Up
Speed-duplex: Auto
Capabilities: 10half, 10full, 100half, 100full
Broadcast storm: Enabled
Broadcast storm limit: 500 packets/second
Flow control: Disabled
Lacp: Disabled
Port security: Disabled
Max MAC count: 0
Port security action: None
Current status:
Link status: Down
Operation speed-duplex: 100full
Flow control type: None
Console#
