C
ONFIGURING
THE
S
WITCH
3-142
Web – Click PoE, Power Config. Specify the desired power budget for the
switch. Click Apply.
Figure 3-61 Setting the Switch Power Budget
CLI – Use the power mainpower maximum allocation command to set
the PoE power budget for the switch.
Displaying Port Power Status
Use the Power Port Status page to display the current PoE power status
for all ports.
Command Attributes
• Port – The port number.
• Admin Status – The administrative status of PoE power on the port.
• Mode – The current operating status of PoE power on the port.
• Power Allocation – The configured power budget for the port.
• Power Consumption – The current power consumption on the port.
• Priority – The port’s configured power priority setting.
Console(config)#power mainpower maximum allocation 200 4-91
Console(config)#
