Q
UALITY
OF
S
ERVICE
C
OMMANDS
4-261
This example creates a class map called “rd_class#1,” and sets it to match
packets marked for DSCP service value 3:
This example creates a class map call “rd_class#2,” and sets it to match
packets marked for IP Precedence service value 5:
This example creates a class map call “rd_class#3,” and sets it to match
packets marked for VLAN 1:
policy-map
This command creates a policy map that can be attached to multiple
interfaces, and enters Policy Map configuration mode. Use the no form to
delete a policy map and return to Global configuration mode.
Syntax
[no] policy-map policy-map-name
policy-map-name - Name of the policy map. (Range: 1-16 characters)
Default Setting
None
Command Mode
Global Configuration
Command Usage
•Use the policy-map command to specify the name of the policy map,
and then use the class command to configure policies for traffic that
matches criteria defined in a class map.
Console(config)#class-map rd_class#1_ match-any
Console(config-cmap)#match ip dscp 3
Console(config-cmap)#
Console(config)#class-map rd_class#2 match-any
Console(config-cmap)#match ip precedence 5
Console(config-cmap)#
Console(config)#class-map rd_class#3 match-any
Console(config-cmap)#match vlan 1
Console(config-cmap)#
