C
ONFIGURING
THE
S
WITCH
3-154
Web – Click Spanning Tree, STA, Information.
Figure 3-67. Displaying Spanning Tree Information
CLI
– This command displays global STA settings, followed by settings for
each port
.
Note: The current root port and current root cost display as zero when
this device is not connected to the network.
Console#show spanning-tree 4-214
Spanning-tree information
---------------------------------------------------------------
Spanning tree mode: RSTP
Spanning tree enabled/disabled: enabled
Priority: 32768
Bridge Hello Time (sec.): 2
Bridge Max Age (sec.): 20
Bridge Forward Delay (sec.): 15
Root Hello Time (sec.): 2
Root Max Age (sec.): 20
Root Forward Delay (sec.): 15
Designated Root: 32768.0012CF0B0D00
Current root port: 0
Current root cost: 0
Number of topology changes: 1
Last topology changes time (sec.):2262
Transmission limit: 3
Path Cost Method: long
.
.
.
