P
ORT
C
ONFIGURATION
3-127
Displaying LACP Settings and Status for the Remote Side
You can display configuration settings and the operational state for the
remote side of an link aggregation.
Web – Click Port, LACP, Port Neighbors Information. Select a port
channel to display the corresponding information.
Table 3-10. LACP Neighbor Configuration Information
Field Description
Partner Admin System
ID
LAG partner’s system ID assigned by the user.
Partner Oper System
ID
LAG partner’s system ID assigned by the LACP protocol.
Partner Admin
Port Number
Current administrative value of the port number for the protocol
Partner.
Partner Oper
Port Number
Operational port number assigned to this aggregation port by the
port’s protocol partner.
Port Admin Priority Current administrative value of the port priority for the protocol
partner.
Port Oper Priority Priority value assigned to this aggregation port by the partner.
Admin Key Current administrative value of the Key for the protocol partner.
Oper Key Current operational value of the Key for the protocol partner.
Admin State Administrative values of the partner’s state parameters. (See
preceding table.)
Oper State Operational values of the partner’s state parameters. (See
preceding table.)
